Using this following procedure to generate Java persistent entities from database tables.
1. File => New => JPA Project => Click Next
2. Assign Project Name => Click Next
3. Click Next
4. Assign Platform and configure database connection => Click Finish
5. The sample JPA project, JPA_Project, had been created
6. Click src => Right Click => New => JPA Entities from Tables
7. Checked the tables which you would like to generate entities => Click Next
8. Click Next
9. Assign package name where your entities would like to place => Click Next
10. Click Finish
11. Check Result
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
| package gov.nta.entity.fms;
import java.io.Serializable;
import java.sql.Timestamp;
import javax.persistence.Column;
import javax.persistence.Entity;
import javax.persistence.Id;
import javax.persistence.NamedQuery;
/**
* The persistent class for the FMS406FF database table.
*
*/
@Entity
@NamedQuery(name = "Fms406ff.findAll", query = "SELECT f FROM Fms406ff f")
public class Fms406ff implements Serializable {
private static final long serialVersionUID = 1L;
@Id
@Column(name = "YYY_MM")
private String yyyMm;
@Column(name = "REMARKS1")
private String remarks1;
@Column(name = "REMARKS2")
private String remarks2;
@Column(name = "REMARKS3")
private String remarks3;
@Column(name = "UPDATE_DATE")
private Timestamp updateDate;
@Column(name = "USER_ID")
private String userId;
public Fms406ff() {
}
public String getYyyMm() {
return this.yyyMm;
}
public void setYyyMm(String yyyMm) {
this.yyyMm = yyyMm;
}
public String getRemarks1() {
return this.remarks1;
}
public void setRemarks1(String remarks1) {
this.remarks1 = remarks1;
}
public String getRemarks2() {
return this.remarks2;
}
public void setRemarks2(String remarks2) {
this.remarks2 = remarks2;
}
public String getRemarks3() {
return this.remarks3;
}
public void setRemarks3(String remarks3) {
this.remarks3 = remarks3;
}
public Timestamp getUpdateDate() {
return this.updateDate;
}
public void setUpdateDate(Timestamp updateDate) {
this.updateDate = updateDate;
}
public String getUserId() {
return this.userId;
}
public void setUserId(String userId) {
this.userId = userId;
}
}
|
