albert's blog: 2008

2008/12/21

2008 台北馬拉松

2008/12/14

OCUP (OMG-Certified UML Professional) Fundamental - experience sharing

http://junyuo.googlepages.com/OCUPOMG-CertifiedUMLProfessionalFund.pdf

2008/12/13

OMG-Certified UML Professional

2008/12/11

Troubleshooting on Tomahawk JSCook Menu

http://wiki.apache.org/myfaces/JSCook_Menu

Check Notes and Known issues.
I had faced this issue Place of Menu tag in relation to Forms:
Menus must be placed inside forms starting with Tomahawk 1.1.3.
With regard to how to do configuration in web.xml, please check http://myfaces.apache.org/tomahawk/extensionsFilter.html

2008/12/10

java.lang.IllegalStateException: ExtensionsFilter not correctly configured. JSF mapping missing. JSF pages not covered.

Error Message

java.lang.IllegalStateException: ExtensionsFilter not correctly configured. JSF mapping missing. JSF pages not covered. Please see: http://myfaces.apache.org/tomahawk/extensionsFilter.html
    at org.apache.myfaces.renderkit.html.util.AddResourceFactory.throwExtensionsFilterMissing(AddResourceFactory.java:389)
    at org.apache.myfaces.renderkit.html.util.AddResourceFactory.checkEnvironment(AddResourceFactory.java:349)
    at org.apache.myfaces.renderkit.html.util.AddResourceFactory.getInstance(AddResourceFactory.java:279)
    at org.apache.myfaces.custom.navmenu.jscookmenu.HtmlJSCookMenuRenderer.addResourcesToHeader(HtmlJSCookMenuRenderer.java:404)
    at org.apache.myfaces.custom.navmenu.jscookmenu.HtmlJSCookMenuRenderer.encodeBegin(HtmlJSCookMenuRenderer.java:363)
    at javax.faces.component.UIComponentBase.encodeBegin(UIComponentBase.java:788)

Solution
If you are using servlets 2.4, you cannot do a jsp:forward or request.getDispatcher().forward to any page, because the extensions filter is not executed. Instead you may want to try with a response.sendRedirect(). Therefore, I need to modify to response.sendRedirect("template-client.jsf");

2008/12/05

Apache Trinidad + Facelets + JPA + JasperReport

Apache Trinidad + Facelets + JPA + JasperReport.ppt from Guo Albert

2008/11/23

Integrate Seam with Apache Trinidad, Facelets and JPA

Agenda

Seam
Seam + JSF
Seam Annotation in JSF Implementation
Seam + JPA (No need to change)
Environment Configuration
Use Case
Page Flow
Class Diagram
Sequence Diagram

http://www.slideshare.net/junyuo/integrate-seam-with-apache-trinidad-facelets-and-jpa-presentation

2008/11/06

Top 10 Project Killers @ Straw Dogs

2008/11/05

Re: [jasperreports-questions] IS_IGNORE_PAGINATION parameter

Re: [jasperreports-questions] IS_IGNORE_PAGINATION parameter

I had faced the same problem regarding exprting report to pdf in browser but bring blank page.
The root cause is the IS_IGNORE_PAGINATION had been set into FALSE, so it cannot diaplay correctly.

2008/10/29

Solution to character broken in JasperReport export PDF problem

View more presentations from Guo Albert

2008/10/28

Highlighting Odd and Even Rows in JasperReports - Brian Burridge

Highlighting Odd and Even Rows in JasperReports - Brian Burridge: "new Boolean( $V{PAGE_COUNT}.intValue() % 2 ==0 )"

In order to highlight odd or even rows with a background color, in JasperReports, first create a rectangle element with a background of your color choice, and send it to the background (in JasperAssistant, right click on the rectangle, choose Arrange and then Send to Back). Second, use the following expression to set when the element should appear, by placing the expression in the Print When Expression field of the rectangle element. Where the $V{PAGE_COUNT} appears, you can use that, to base it on the row number on the page, or use $V{REPORT_COUNT} to base it on the row within the report. Also, if you are using a group, you can use $V{groupname_COUNT} where groupname is replaced with the name of your group. The expression below will then test the row number within the Page, Report, or Group (whichever you selected) and if its divisible by 2, it will display the rectangle element with the background color.

2008/10/25

CAS (Central Authentication Service) Enhancement

Agenda

Why SSO (Single-Sign On)?
Central Authentication Service (CAS)
CAS Installation
As-Is and To-be Process
Modification Process

http://www.slideshare.net/junyuo/cas-enhancement-presentation

2008/10/21

97 Things Every Software Architect Should Know

Facelets with Trinidad - Myfaces Wiki

Facelets with Trinidad - Myfaces Wiki

This article is used to explain how to integrate Facelets with Trinidad.

2008/10/02

CAS Demo Application Installation

CAS Demo Application Installation

including troubleshooting (CAS Demo App. cannot be running correctly)

2008/09/20

Joda Time - Java date and time API - Home

Joda Time - Java date and time API - Home

Joda-Time provides a quality replacement for the Java date and time classes. The design allows for multiple calendar systems, while still providing a simple API. The 'default' calendar is the ISO8601 standard which is used by XML. The Gregorian, Julian, Buddhist, Coptic, Ethiopic and Islamic systems are also included, and we welcome further additions. Supporting classes include time zone, duration, format and parsing.

2008/09/19

Spring + JPA + TOPLink + DAO Step by Step

Spring + JPA + TopLink + DAO Architecture
Spring/Persistence Config File
Implement DAO – CRUD
Implement ServiceBean
Implement Client Side Code

http://www.slideshare.net/junyuo/spring-toplinkjap-dao-step-by-step-presentation

2008/09/03

Spring + JPA + DAO Step by Step

Spring + JPA + DAO Architecture
Spring Config File
Implement DAO – CRUD
Implement ServiceBean
Implement Client Side Code

http://www.slideshare.net/junyuo/spring-jpa-dao-step-by-step-presentation

2008/08/31

Java Persistence API (JPA) Step By Step

What is Java Persistence API
Primary Features
Five Steps to Implement JPA

Download Hibernate Components
Prepare Database, and Download JDBC Driver
Implemented POJO entities and add annotations
Persistence.xml
Implemented client side code via EntityManager

http://www.slideshare.net/junyuo/java-persistence-api-jpa-step-by-step-presentation

2008/08/20

York University Summer Language Program

2008/06/29

Applied MyEclipse and JUnit to do Hibernate Code Gen and Testing

• Hibernate Code Generation
• Code Gen Process
• Generate DAO for the four tables
• Artifacts
• Spring Configuration File
• Apply JUnit to do DAOs Test
• JUnit Framework
• How to Test with JUnit?
• Simplified Workflow of Applying JUnit
• Testing Process
• Generate Unit Test Result via Ant

http://www.slideshare.net/junyuo/applied-myeclipse-and-junit-to-do-hibernate-code-gen-and-testing/
